Tag: PropertyAnalyzer

The PropertyAnalyzeraction, along with a set of nested SetParam child actions, automates the Property Analyzer process.


Detailed Description

The action <PropertyAnalyzer/> alone, will run the Property Analyzer using the current default settings.

Running the action with a set of nested SetParam actions, will trigger the 'Save Settings and run analyzer' options and the fields to set corresponding options as found in the Property Analyzer dialog.

SetParam Options

Field NameCompatible Field Values
TemplateNamesDuplicatesTrue / False
ReplicaIDDuplicatesTrue / False
InheritFromGhostTemplateTrue / False
DBPercentageOfQuotaRemainingTrue / False
DBPercentageOfQuotaRemainingValueUser defined number
NoDataChangeSinceTrue / False
NoDataChangeSinceValueUser defined number
DesignChangeWithinLastTrue / False
DesignChangeWithinLastValueUser defined number
DBSpecificSizeTrue / False
DBSpecificSizeValueUser defined number
LaunchAnalyzerOnStartupTrue / False

Example Scripts

<PropertyAnalyzer>
	<SetParam Field="TemplateNamesDuplicates" Value="True"/>
	<SetParam Field="ReplicaIDDuplicates" Value="True"/>
	<SetParam Field="InheritFromGhostTemplate" Value="True"/>
	<SetParam Field="DBPercentageOfQuotaRemaining" Value="True"/>
	<SetParam Field="DBPercentageOfQuotaRemainingValue" Value="1"/>
	<SetParam Field="NoDataChangeSince" Value="True"/>
	<SetParam Field="NoDataChangeSinceValue" Value="2"/>
	<SetParam Field="DesignChangedWithinLast" Value="True"/>
	<SetParam Field="DesignChangedWithinLastValue" Value="3"/>
	<SetParam Field="DBSpecificSize" Value="True"/>
	<SetParam Field="DBSpecificSizeValue" Value="4"/>
	<SetParam Field="LauncheAnalyzerOnStartup" Value="False"/>
</PropertyAnalyzer>
XML
<ytriaAutomation>
	<Load Server="Acme01/ACME"/>
	<PropertyAnalyzer>
		<SetParam Field="TemplateNamesDuplicates" Value="True"/>
		<SetParam Field="ReplicaIDDuplicates" Value="True"/>
		<SetParam Field="InheritFromGhostTemplate" Value="True"/>
		<SetParam Field="DBPercentageOfQuotaRemaining" Value="True"/>
		<SetParam Field="DBPercentageOfQuotaRemainingValue" Value="1"/>
		<SetParam Field="NoDataChangeSince" Value="True"/>
		<SetParam Field="NoDataChangeSinceValue" Value="2"/>
		<SetParam Field="DesignChangedWithinLast" Value="True"/>
		<SetParam Field="DesignChangedWithinLastValue" Value="3"/>
		<SetParam Field="DBSpecificSize" Value="True"/>
		<SetParam Field="DBSpecificSizeValue" Value="4"/>
		<SetParam Field="LauncheAnalyzerOnStartup" Value="False"/>
	</PropertyAnalyzer>
</ytriaAutomation>
XML

In the script above, the Property Analyzer will be saved and run using the settings specified in the SetParam child actions
