DynamicFormat: Set cell background color from formula

Tag: DynamicFormat

The DynamicFormat function allows dynamic (or conditional) cell formatting with a formula that compares the cell value to a set of conditions.

As of 2025 (sapio365 v3, EZsuite v25), only background cell color is enabled.

Tag Attributes

Attributes	Attribute Values	Value Description
Target	The corresponding Grid Code	Sets the target grid on which the action will be applied - Not Required If no target is set, the target will default to the main grid (for products containing a main grid).
ColumnID	The corresponding Column ID, as shown in the Grid Manager	Sets the column on which the action will be applied - Required
Color	Number value of the color	Integer RGB value set as a decimal number: 255 (Red) or a hexadecimal notation prefixed with #: #00FF00 (green)

Attributes

Attribute Values

Value Description

Target

The corresponding Grid Code

Sets the target grid on which the action will be applied - Not Required
If no target is set, the target will default to the main grid (for products containing a main grid).

ColumnID

The corresponding Column ID, as shown in the Grid Manager

Sets the column on which the action will be applied - Required

Color

Number value of the color

Integer RGB value set as a decimal number:

255 (Red)

or a hexadecimal notation prefixed with #:

#00FF00 (green)

Then insert inside the DynamicFormat block the Filter actions that build the formula. The cells whose values match the list of Filter shall be formatted (Color set).

Code Example

<ytriaAutomation Console="False">

red decimal
    <DynamicFormat Color="255" ColumnID="userPrincipalName">
        <Filter Contains="c" Mode="Text"/>
	</DynamicFormat>

green hexa
    <DynamicFormat Color="#00FF00" ColumnID="userPrincipalName">
        <Filter Contains="w" Mode="Text"/>
	</DynamicFormat>

</ytriaAutomation>
